Alogic Aspekt 34" ultrawide touch monitor (3K)

Experience expanded multitasking with Touch x Ultrawide

Providing a desktop experience that stands out, Aspekt Ultrawide Touch merges the expansive multitasking capacity of our Edge Ultrawide Monitors with the smooth touchscreen capabilities of our Aspekt Touch monitors.

Navigating with ease on Mac and Windows

The precision touchscreen from Aspekt allows for a range of functions from tapping to pinching, swiping and using all your favourite multitouch shortcuts - whether you're a Windows user or a Mac enthusiast.

Designed for digital creatives

Partnered with our ALOGIC Active Stylus, Aspekt Touch becomes a 34” sketchpad with 4096 levels of pressure sensitivity. This is perfect for sketching, painting or annotating documents, such as architectural diagrams.

Comfort meets innovation with the ergonomic fold stand

The Aspekt Fold Stand is a unique feature that smoothly lowers the ultrawide screen down to your desk for drawing or note-taking. It then easily raises back up for regular use.

Exceptional resolution with UWQHD

With Aspekt Ultrawide's high resolution 3440x1440 screen, you'll see the full scope of your current project. Whether it's a blueprint, an Excel spreadsheet, or scenes in Final Cut Pro, you'll have a clear, comprehensive view.

Multitasking has never been simpler

Aspekt Ultrawide is designed to replace two monitors with one expansive touchscreen, making multitasking a breeze. Simply drag your windows to either end of the screen and watch as they neatly tile together.

Colour accuracy you can trust

Aspekt’s screen is designed with creatives in mind, boasting a strong colour gamut coverage (100% sRGB, 94% DCI-P3) with an average Delta E < 2. This results in a wide range of true-to-life colours, ensuring accurate representation for digital or print projects.

Features

• Screen Size: 34”
• Panel Type: IPS with Matt Finish
• Backlight Type: LED
• Screen Finish: Matt
• Aspect Ratio: 21:9
• Resolution: 3440x1440
• Refresh Rate: 100Hz
• Pixel Density: 109 PPI
• Brightness: 400 nits (Typical)
• Contrast Ratio (Static): 1000:1
• Response Time: 14ms (Grey to Grey)
• Bit Depth: 8 bit + FRC
• Colour Gamut Coverage: 100% sRGB, 90% Adobe RGB, 94% DCI-P3
• Avg. Delta E: <2
• HDR: HDR 400 Compatible
• Touchscreen: 10 Point Capacitive Touchscreen
• Stylus Compatibility: Compatible with MPP 2.0 Active Styluses
• VESA Mount: 100x100mm
• Audio: Speakers: 5Wx2 | Audio Out: Yes

Design

• Colour: Space Black

Materials

• ABS, Glass, Aluminium

Physical

• Upright on Fold Stand: 825mm x 490mm x 335mm (L x H x D)
• Monitor Only: 825mm x 375mm x 48mm (L x H x D)
• Monitor Only Weight: 9.15kg
• Fold Stand Weight: 5.55kg

Connectivity

• 1x HDMI 2.0 Input
• 1x DisplayPort 1.4 Input
• 1x USB-C Host Input w/90W PD (DP Alt Mode)
• 1x DisplayPort Output for Daisy Chain (MST)
• 1x USB-C Device Input w/15W PD (Rear Port)
• 1x USB-A Device Input w/5W PD (Rear Port)
• 1x USB-C Device Input w/30W PD (Side Port)
• 1x USB-A Device Input w/5W PD (Side Port)
• 1x USB-C Device Input w/5W PD (Top Port)
• 1x 3.5mm Headphone Jack
• 1x Gigabit Ethernet RJ45
• 1x Security Lock Slot

Power

• Power Input: AC 100V-240V~ 50/60Hz, DC 24V⎓8A, 192W Max

What's in the box

• Aspekt Ultrawide Touch Monitor
• USB-C Cable
• HDMI Cable
• DisplayPort Cable
• Power Adapter
• User Manual
